Digital 3 Phase Voltmeter

Model: ASK-333V

Immutable results against vibrations and shock as per IEC-61373

Performance assured against fire incidents as per the European safety standard EN45545 HL-2

Data Sheet

ParametersSpecification
ParametersVoltage Line to Line & Line to Neutral
Ranges0-800Vpp
Accuracy1.0% of FSD
Display14.2mm LED Red
Auxiliary Power Supply80-270Vac @50Hz, 4VA
(Optional:10-40 DC 1VA)
Meter SizeABS Plastic Housing for FR Grade Material
a)96mm x 96mm x 45mm (Cut out Size:92/92mm)
Input impedance1MΩ
Operating Temperature10°C to 55° C
Relative humidity0– 90%.
FeaturesMicrocontroller based meters with low VA burden
4 digit three row seven segment display
PT primary range 50V to 500kV AC programmable
PT Secondary 50V to 500V AC programmable
Password protected
True RMS measurement of parameters
Auto scaling of parameter values
Auto/Manual scrolling of parameters
Two switches for easy onsite programming.
